Overview
From ingenuity and independent thinking, the Maverick was born. Named in the spirit of the pioneer Samuel A. Maverick, this classic dump body became the foundation on which our reputation of rugged reliability was formed and later the industry standard. Exceptional value, flexible design, easy cleanout, and capable of handling light, medium, and heavy duty loads. It’s where it all began, rugged reliability “As Strong As An Ox”.
Materials
- Front / Sides: 10 ga
- Floor / Tailgate: 3/16″
- Top rail: 4″ x 4″ 11 ga square tubing
- Longsill: 2″ x 8″ 3/16″ rectangular tubing
- Crossmembers: 1.5″ x 3″ rectangular tubing
Specifications
- Lengths: 10′-22′ – Width (ID/OD): 87″/96″
- Side Heights: 18″- 72″
- Capacities: 3.9 to 34.6 cubic yards
- Square dump body design
- Crossmembers on 12″ centers
- Telescoping Hoist
Features and Options
- Heavy duty, steel removable tailgate hinge pin
- Exterior ladder/interior rungs
- In-Cab controls
- Air actuated tailgate
- Tailgate spreader chains
- Back up alarm
- Body up indicator
- Material upgrade options
- Tailgate options
- Heated understructure
- Custom paint colors available
